GY60-2-NO11 Chain Connecting Link, 3/4" Pitch ANSI, Duplex

Name: GY60-2-NO11 Chain Connecting Link, 3/4" Pitch ANSI, Duplex
Brand: Renold Synergy
SKU: GY60-2-NO11
Price: 21.05 GBP
Availability: InStock

Product code: GY60-2-NO11

Chain Connecting Link, 3/4" Pitch American Standard, Duplex, Renold Synergy

Product information

Simply the best. Strong, powerful, even better in performance.

Chain Connecting Link to suit GY60-2, 3/4" Pitch American Standard, Duplex.

Synergy is the only true high-performance chain on the market. Engineers and maintenance professionals around the world endorse the wear resistance and exceptional working life of this remarkable chain technology. Newly specially formulated lubricant has improved initial wear life by up to 50%. Renold Synergy should be lubricated as normal when in operation.

Chain Dimensions - 60-2
Pitch mm (A)	19.050
Pitch inch (A)	0.750
Inside Width mm (B)	12.57
Roller Diameter mm (C)	11.91
Plate Height mm (D)	17.50
Plate Width Inner (E)	2.45
Plate Width Inner (F)	2.45
Pin Diameter mm (G)	5.94
Pin Length mm (H2)	48.1
ISO Tensile Strength (Min)	62600
Weight Per Meter kg/m	2.91
